Viborg VM501S US AC Connector Pure Copper, Silver-plated

Click to Zoom
Viborg VM501S US AC Connector Pure Copper, Silver-plated

This is the first in the series of Viborg's VM501 straight US mains plug. All pins and contacts are made from pure copper, OFC copper-plated and then silver-plated.

Specifications:

  • Conductor: Pure copper, OFC copper-plated and then silver-plated
  • Body. Black nylon / fibreglass
  • Body dimensions: 53mm length x 33mm diameter
  • Overall length: 72mm
  • Wire connections via pozidrive screw.
  • Maximum cable diameter: 19mm
  • Rating: 15A 125Vac

PRICE (1 off)
£14.30 +vat +p&p

Big Picture
Rear view219.25 KB
Internal view260.72 KB
